MÁY NÉN KHÍ PISTON CAO ÁP 15 BAR, HERTZ - GERMANY
- Model: HPC-T5
- Lưu lượng từ : 507 lít/phút
- Công suất: 4.0/5.5 (KW/HP)
- Áp suất làm việc max: 15 Bar
- Kiểu làm mát: Gió
- Nguồn cấp: 380V/3Ph/50Hz or 60Hz
- Ứng dụng cho ngành công nghiệp hàng hải và các ngành công nghiệp cần đến áp suất sử dụng lên đến 15Bar.
Double Stage Reciprocating Air CompressorsModel: HPC – T2/200 / HPC – T5 / HPC – T7 / HPC – T10
Model(*) | Pressure | Capacity | Motor Power kW/HP | Connection Size | Dimensions mm | Weight | Air Receiver (3) |
Bar | PSI | lt/min | SCFM | Width | Depth | Height | kg | lt |
Single-Stage Reciprocating Series |
HPC-S1 | 8 | 115 | 205 | 7.2 | 1,1/1,5 | 1/2” | 1202 | 426 | 894 | 93 | 80 |
HPC-S2 | 8 | 115 | 327 | 11.5 | 1,5/2,0 | 1/2” | 1202 | 426 | 914 | 106 | 80 |
HPC-S3 | 8 | 115 | 410 | 14.5 | 2,2/3,0 | 1/2” | 1531 | 450 | 1037 | 135 | 200 |
HPC-S5 | 8 | 115 | 607 | 21.4 | 4,0/5,5 | 1/2” | 1830 | 466 | 1145 | 209 | 250 |
HPC-S7 | 8 | 115 | 1013 | 35.8 | 5,5/7,5 | 3/4” | 1927 | 664 | 1291 | 308 | 500 |
HPC-S10 | 8 | 115 | 1657 | 58.5 | 7,5/10 | 3/4” | 1926 | 668 | 1413 | 390 | 500 |
Double-Stage Reciprocating Series |
HPC-T2/200 | 12 | 175 | 205 | 7.2 | 1,5/2,0 | 1/2” | 1532 | 450 | 983 | 145 | 200 |
HPC-T5 | 15 | 215 | 507 | 17.9 | 4/5,5 | 3/4” | 1832 | 474 | 1097 | 230 | 250 |
HPC-T7 | 12 | 175 | 856 | 30.2 | 7,5/10 | 3/4” | 1920 | 658 | 1298 | 374 | 500 |
HPC-T10 | 15 | 215 | 828 | 29.2 | 7,5/10 | 3/4” | 1925 | 669 | 1406 | 439 | 500 |
* HERTZ KOMPRESSOREN reserves its rights to make changes in its products and specifications without prior notice. |
TIME PROVEN DESIGN Thanks to continuous development and innovation of material, machining and assembly techniques, HERTZ products will exceed your expectations.
LONG LIFE Cast-iron crankcase and cylinders, pistons operated at low-speed, corrosion and heat-resistant stainless steel valves, cylinders and bare pumps with cooling fins make HERTZ HPC series reciprocating air compressors durable and problem free.
USER FRIENDLY DESIGN All HERTZ models are manufactured to suit a broad range of applications, have easy & minimum maintenance, long maintenance intervals and low operating costs. All spare parts are easily accessible at all service locations across the widespread after-sales service network.
COMPRESSOR BLOCK
- Heavy duty cast-iron crankcase
- Cast-iron cylinders with cooling fins
- Sphero cast crankshaft
- Lightweight pistons and special aluminum cast connecting rods
- Special design finger-type high capacity and high pressure-resistant inlet-outlet valves
- Compression and oil retaining rings
SAFETY SYSTEMS- Blow down valve for loadless start (for 4kW motor power and more)
- Pressure switch
- Non-return valve
- Belt-pulley guard
- Safety valve
- Manometer
MAIN MOTOR AND DRIVE SYSTEM- High efficiency 400V/3 phase/650Hz IE3 class IP55 electric motor
- Drive system with belt-pulley mechanism
- Belts have a working life of minimum 25,000 hours
- Special design fan type cast-iron pulley
- Easy adjustment belt tension
OTHER FEATURES- CE certified air receiver made from P265GH pressure vessel steel
- Long-lifetime bearings
- Air intake filter and silencer for loadless operation
- Oil splash lubrication system
- Oil level indicator
OPTIONS- Automatic condensate drain valve for air receiver
- Thermic magnetic circuit-breaker (up to 4kW motor power)
- Motor drive system with star-delta connection(between 5.5-7.5 kW motor power)
- Soft-starter
- Power supply options other than 400V/3 phase/50Hz
|
